Energy meter Shelly PM mini GEN3, 16A

Description

⚡ Shelly PM Mini Gen3 - Ultra-compact, 16A Wi-Fi smart energy meter with advanced Shelly features

Control and monitor energy consumption in the tightest of spaces with the Shelly PM Mini Gen3 - a small in size, but full-featured smart meter from the Shelly Plus range. Ideal for cramped fixtures, appliances or switchboards, this module just 29mm wide gives you accurate metering, smart automation and full integration into the Shelly ecosystem.

✨ Key features:

📏 Ultra-compact size - just 29 x 34 x 16 mm
35% smaller than standard Shelly Plus relays - perfect for narrow wall boxes, concealed installations or direct embedding into appliances.

📡 F ull control via Wi-Fi and Bluetooth
Quick and reliable connection - initial set-up via Bluetooth, stable operation via 2.4GHz Wi-Fi, no external hub.

📊 A ccurate power consumption monitoring
Measures voltage, current and active power in real time - perfect for optimising consumption and cutting costs.

📆 S mart programmes and scenes
Set customised schedules or sunrise/sunset automations - integrate with other Shelly devices for complex scenes.

💻 Advanced scripting & webhooks
Full support for mjS scripting, MQTT, HTTP/HTTPS webhooks and open protocols - ideal for advanced users and integrators.

Extensive compatibility
Works with the Shelly Smart Control app, Google Home, Amazon Alexa and any MQTT compatible automation system.

🛠️ Ideal for:

• 🔌 Narrow switch boxes (e.g. standard Danish)

• 🧺 Direct embedding in home appliances

• 💡 Discreet control of lighting circuits or sockets

• 📈 Efficient monitoring of areas with loads up to 16A

📐 Technical specifications:

• Model: Shelly Plus PM Mini PM Gen3

• Dimensions: 29 x 34 x 16 mm

• Weight: 13 g

• Mounting: In wall box or in appliance

• Power supply: 110-240V AC

• Power consumption: < 1,2 W

• Max. measuring current: 16 A

• Max. power: 3840 W

• Connectivity: Wi-Fi 802.11 b/g/n, Bluetooth 4.2

• RF protocol: 2400-2495 MHz, <20 dBm

• CPU: ESP32, 4 MB Flash

• Advanced features: mjS scripting, MQTT, Webhooks (20 with 5 URLs), UDP

• Internal temperature sensor: Yes

• Wi-Fi range: up to 30 m indoor / 50 m outdoor

• Bluetooth range: up to 10 m indoor / 30 m outdoor

• Protections: no automatic overload cut-off

• Voice compatibility: Google Assistant, Amazon Alexa

🔧 Compact, powerful and ready for any scenario - the Shelly PM Mini Gen3 is the ideal solution for smart energy control in tight spaces.
