FC311A-2

Gigabit WDM Media Converter - TP-Link TL-FC311A-2
🌐 Connect Ethernet networks up to 2km using a single fibre

⚙️ What does this product do?

The TL-FC311A-2 Media Converter TL-FC311A-2 converts the signal between a Gigabit RJ45 port and an SC port over single-mode fibre, ideal for scenarios such as remote video surveillance or fibre-optic-to-peripheral network extension(tp-link.com, tp-link.com).

🔬 Efficient WDM technology

• Uses WDM technology to transmit and receive data over a single fibre, saving cables and infrastructure(tp-link.com).

• Transmits at 1550 nm, recognises at 1310 nm - must work in conjunction with TL-FC311B-2 for two-way communication(tp-link.com).

🛠️ Technical Features

• Ports:
  - 1× RJ45 Gigabit (10/100/1000 Mbps) with Auto-MDI/MDIX
  - 1× single-mode SC port(tp-link.com).

• Transmission distance: up to 2 km over 9/125 μm fibre(tp-link.com).

• Auto-negotiation for Half/Fullduplex mode(tp-link.com).

• IEEE standard: 802.3i/u/ab/z(tp-link.com).

• Environmental conditions: 0-50 °C operation, -40-70 °C storage, 10-90 % non-condensing humidity(tp-link.com).

• Power: 5 V/0.6 A external adapter; LED indicators for PWR and Link/Act(tp-link.com).

• Compact size: ~95 × 73 × 27 mm (tp-link.com).

✅ Advantages in wifishop.co.uk style

• Save fibre - WDM allows the use of a single line for transmission and reception over distances up to 2 km.

• Plug-&-Play - automatic Ethernet negotiation without additional settings.

• Compact and robust - ideal for discreet rack (TL-FC1420) or desktop wallmount installations.

• Guaranteed compatibility - use alongside TL-FC311B-2 for ideal fibre deployments(tp-link.com, tp-link.com).

🎯 The TP-Link TL-FC31111A-2 is the efficient and professional solution for extending Gigabit networks over fibre, ideal for surveillance, wireless backhaul or campus networking in a compact and easy-to-use form factor.
