Media Converter TP-Link MC100CM

Fast Ethernet Multi-Mode Media Converter - TP-Link MC100CM
📡 Extend your network over multi-mode fibre, quickly and easily

The TP-Link MC100CM is a compact and reliable media converter designed to convert the signal between 100Base-FX (multimode fibre) and 100Base-TX (copper Ethernet), providing connectivity over distances of up to 2 km. Ideal for network links between buildings, campuses, IP cameras or parks.

🚀 Full-duplex Fast Ethernet (10/100 Mbps)
On both interfaces - RJ45 port and SC port for fibre(omadanetworks.com, cdw.com, static.tp-link.com).

🔌 S tandard ports

• 1× RJ45 10/100 Mbps port with auto MDI/MDIX

• 1× multimode SC port (1310 nm) for fibre(omadanetworks.com)

📏 Long distance extension
Enables transmissions up to 2 km (1.2 miles) over multimode fibre .

🔁 Auto-negotiation and full-duplex control
IEEE 802.3x flow-control support with half/full duplex mode(omadanetworks.com).

⚠️ Link Fault Pass-Through (LFP)
Detects link failures and automatically transmits status to the other interface for network stabilisation(tp-link.com, officecrave.com).

🌡️ Front LEDs for monitoring
LEDs for power, link status/activity and speeds, providing clear visibility of operation .

🔧 Plug & Play installation
No configuration - can be used standalone or integrated into TL-MC1400 chassis(surveillance-video.com).

🔌 External power supply, low power consumption (~2.4 W)
Includes plug adapter, maintaining optimal performance with minor impact on power consumption .

✅ Ideal for: links between buildings or campuses, IP cameras, medium distance industrial networks
✅ S peed: 10/100 Mbps full-duplex
Fibre distance: up to 2 km (multimode)
Connector: SC multimode
✅ Support: IEEE 802.3, 802.3u, 802.3x
✅ Dimensions: 95 × 73 × 27 mm; weight ~0.8 lb(omadanetworks.com, officecrave.com)

💼 TP-Link MC100CM - the simple and efficient media converter, perfect for extending Fast Ethernet networks over multimode fibre, without technical complexity, with professional stability.
