Open box Shelly Wave 1 Mini LR – Smart Z-Wave Long Range relay for automated control
Description
What does "open box" mean?
Open-box products are returned products with opened or damaged packaging, but fully checked from a technical point of view and completely functional. They come with the same warranty as new products.
Shelly Wave 1 Mini LR – Ultra-compact Z-Wave Long Range smart relay
Shelly Wave 1 Mini LR is a new-generation smart relay from the Shelly Wave series, running on the Z-Wave Long Range protocol, offering extended communication range and improved stability in smart home networks.
With an ultra-compact design, this model is perfect for installation in wall boxes, switches or light fittings, giving you full control over lights and sockets.
Main functions
-
ON/OFF control for electrical circuits of up to 8A (2000W at 240V AC)
-
Compatible with the Z-Wave 800 LR standard – extended range and stable connectivity
-
Local operation and integration into existing Z-Wave networks
-
30% smaller than standard Shelly Wave models
-
Support for direct association and automated scenes
-
Compatible with Z-Wave JS, Z-Wave JS UI and other smart home integration platforms
-
Overtemperature and overvoltage protection
-
Physical reset function for quick setup
Technical specifications
-
Power supply: 110–240V AC / 24–30V DC
-
Maximum current: 8A
-
Maximum power: 2000W at 240V AC
-
Communication protocol: Z-Wave Long Range 800
-
Frequency band: 868.4 MHz (EU)
-
Range: up to 1 km in open field
-
Dimensions: 29 x 35 x 16 mm
-
Operating temperature: –20°C to +40°C
-
Self-consumption: <0.3W
User benefits
-
Miniature dimensions for installation in tight spaces
-
Extended range and stable communication thanks to Z-Wave Long Range technology
-
Simple installation and easy integration into existing Z-Wave systems
-
Local control and advanced automations without an internet connection
-
Extended compatibility with Z-Wave controllers and automation platforms
Practical use cases
- It integrates into an existing Z-Wave network (Z-Wave hub, Home Assistant with a Z-Wave stick, or another compatible controller), extending home automation without adding a new ecosystem.
- Installed behind a switch or socket, it works as a Z-Wave relay, benefiting from the extended coverage and stability typical of this protocol, ideal in buildings with thick walls.
- Each Wave device also works as a repeater in the Z-Wave mesh network, helping to extend the signal to other, more distant nodes.
- Note: Requires a compatible Z-Wave hub/controller (e.g. Home Assistant with a Z-Wave adapter) to be connected to the network and controlled from the app.
