Shelly Qubino Wave Pro 1, 16A, 1 channel, Z-Wave

Description

⚙️ Shelly Qubino Wave Pro 1 - Professional Z-Wave® Relay, 1 channel, dry contact, DIN mount

Reliable automation for residential and commercial projects - The Shelly Qubino Wave Pro 1 is a high-performance, 1-channel, 1-channel Z-Wave® relay with up to 16 A output, ideal for controlling lights, sockets or other electrical consumers. It mounts directly to DIN rail and offers a high degree of flexibility due to its potential-free output (dry contact).

✅ Main advantages:

🔌 1 channel - up to 16 A - Reliable control for lighting and medium power appliances
📦 DIN rail mountable - Ideal for switchboards in residential or commercial buildings
⚡ Dry contact (potential free) - Compatible with both low and high voltages
Z-Wave 800 (S800) technology - Next-generation connectivity, increased autonomy and stability
🔐 S2 Advanced Security - Encrypted communication for complete protection of your smart network
📲 SmartStart & OTA updates - Automatic setup and effortless firmware updates
🔁 Integrated Z-Wave® repeater - Extends and stabilises your local Z-Wave network
🌡️ Overheat protection - Automatic shutdown for increased safety
🌍 Low power consumption: less than 0.3 W

🧠 Smart automation:

🏠 E fficient lighting control - Programme separate scenes for each floor or zone
🔌 Plug automation - Switch off power during off hours for real savings
🚗 Common Space Management - Smart lighting in hallways, garages, garages, garages, etc.

⚙️ Technical specifications:

• Power supply: 110 - 240 V AC, 50/60 Hz

• Maximum output: 16 A at 240 V AC

• Own consumption: < 0.3 W

• Output: Dry contacts

• Overheat protection: Yes

• CPU: Z-Wave® S800

• RF Frequency: 868.4 MHz

• Emitted power: < 25 mW

• Operating distance: up to 40 m indoors (depending on local conditions)

• Works as Z-Wave® repeater: Yes

• Dimensions: 94 x 19 x 69 mm

• Weight: 60 g

• Mounting: DIN rail

• Screw terminals: max. 0.4 Nm

• Conductor cross-section:

  • Green: 0.5 - 2.5 mm²

  • White: 0,5 - 1,5 mm²

• Conductor cut-out length:

  • Green: 6 - 7 mm

  • White: 5 - 6 mm

• Housing material: Plastic, blue colour

• Operating temperature: -20°C to +40°C

• Humidity: 30% - 70% RH

• Maximum altitude: 2000 m

🔗 The Shelly Qubino Wave Pro 1 is the ideal professional solution for precise, safe and efficient automation in any Z-Wave® based smart system. Compatible with all certified hubs including Home Assistant, Fibaro, SmartThings and more.

📦 Z-Wave® Gateway not included. It is required for configuration and network integration.
