Shelly Wave 1 Mini LR - Ultra-compact Z-Wave Long Range Smart Relay

The Shelly Wave 1 Mini LR is a new generation of the Shelly Wave series of intelligent relays, operating on the Z-Wave Long Range protocol, offering extended communication range and improved stability in smart home networks.
Featuring an ultra-compact design, this model is perfect for mounting in wall sockets, switches or lighting fixtures, offering complete control over lights and sockets.

Main functions

• ON/OFF control for electrical circuits up to 16A (3840W at 240V AC)

• Compatible with Z-Wave 800 LR standard - extended range and stable connectivity

• Local operation and integration into existing Z-Wave networks

• 30% smaller size than standard Shelly Wave models

• Support for direct pairing and automated scenarios

• Compatible with Z-Wave JS, Z-Wave JS UI and other smart home integration platforms

• Over-temperature and over-voltage protection

• Physical reset function for quick configuration

Technical Specifications

• Power supply: 110-240V AC / 24-30V DC

• Maximum current: 16A

• Maximum power: 3840W at 240V AC

• Communication protocol: Z-Wave Long Range 800

• Frequency Band: 868.4 MHz (EU)

• Range: up to 1 km in open field

• Dimensions: 29 x 36 x 16 mm

• Operating temperature: -20°C to +40°C

• Power consumption: <1W

User benefits

• Miniature size for installation in confined spaces

• Extended range and stable communication thanks to Z-Wave Long Range technology

• Simple installation and easy integration into existing Z-Wave systems

• Local control and advanced automation without internet connection

• Extended compatibility with Z-Wave controllers and automation platforms
