SM6110-SR
Description
Omada 25 GBASE-SR Transceiver - TP-Link TL-SM6110-SR
🚀 High-speed optical-to-multimode connection for high-performance data centres and backhaul
🔧 What does this product do?
The TP-Link TL-SM6110-SR is a 25 GBASE-SR SFP28 25 GBASE-SR SFP28 transceiver for high-speed fibre-optic multimode connections, compatible with Omada switches and other equipment with SFP+/SFP28 ports. Provides dual-rate flexibility (25G and 10G) for simple overclocking over short distances.(static.tp-link.com)
⚙️ So what do you actually get?
| Feature | Details |
|---|---|
| Form-Factor | SFP28 hot-pluggable |
| Rate date | Dual-rate: 25.78 Gbps & 10.31 Gbps(static.tp-link.com) |
| Maximum distance | - OM3: 70 m at 25G; 300 m at 10G |
:contentReference[oaicite:7]{index=7} :contentReference[oaicite:8]{index=8} || Wavelength | 850 nm VCSEL / PIN |
| Connector | Duplex LC/UPC |
| Power consumption | ≤ 1 W |
| DDM monitoring | Yes | |
| Operating Temperature | 0 °C - 70 °C (storage down to -40 °C) |
| Compatibility | Standard IEEE 802.3ae/by; SFP28 MSA |
| Reliability | CE, FCC, RoHS; hot-swappable |
✅ Why choose it?
-
Adaptive speed - 25G reliability and backward compatibility with 10G equipment
-
Short-fibre performance - perfect for rack deployments and links between switches in the same server-room
-
Low power and diagnostics - ＜ 1 W power consumption and included DDM for easy monitoring
-
Plug-&-Play - SFP28 MSA support, compatible with Omada SX6632YF, SG3428X, SG3452X etc.(static.tp-link.com)
🎯 Ideal for:
-
Data centres and rack backhaul
-
Enterprise environments with 25 Gbps networks
-
Performance booster for high-density Omada networks
-
Ultra-fast Wi-Fi solutions or high-throughput avec high-throughput servers
💼 The TL-SM6110-SR is the compact, rugged, high-performance transceiver for business networks, offering fast and efficient support for 25G over multimode fibre, with backward compatibility to 10G. Silent, power efficient and guaranteed performance.
