SM9110-SR4
Description
Omada 100GBASE-SR4 Transceiver - TP-Link TL-SM9110-SR4
🚀 10 0 Gbps transfer for high-performance multi-mode networks
🔧 What's in the TL-SM9110-SR4?
The TP-Link TL-SM9110-SR4 is a QSFP28 100GBASE-SR4 compatible multi-mode networking (MMF) transceiver for Omada switches and other QSFP28/QSFP+ compatible equipment. The optical-multimode connection at ultra-high bandwidths brings a top-of-the-line backhaul to data centres, campus networks and next-generation infrastructure.(static.tp-link.com)
📊 Technical Specifications
| Feature | Details |
|---|---|
| Form-Factor | QSFP28 (quad small form-factor) |
| Double speed | 100 Gbps (4×25.78) and 40 Gbps (4×10.3)(omadanetworks.com, static.tp-link.com) |
| Wavelength | 850 nm VCSEL transmit / PIN receiver |
| Connector | MTP/MPO-12 multimode fibre |
| Maximum distance | OM3 - up to 70 m at 100G, OM4 - up to 100 m at 100G (and 150 m at 40G) |
| DDM monitoring | Yes - digital performance monitoring |
| Hot-swappable | Allows replacement without shutdown |
| Operating temperature | 0 °C to 70 °C |
| Power consumption | ~1.8 W @100 G, ~1.54 W @40 G |
| Standard compatibility | IEEE802.3bm/ba, MSA QSFP28, SFF-8665/36/36/8436, CPRI |
| Dimensions | 124×18.35×11.7 mm |
| Certifications | CE, FCC and RoHS to global standards |
✅ Why is it worth it?
-
Exceptional bandwidth - supports 100G and automatically degrades to 40G if equipment is not compatible(static.tp-link.com)
-
Flexible mounting - hot-plug switching interface and compact form-factor
-
Reliability & Efficiency - low power consumption, DDM type for diagnostics, increased operating temperature
-
Ideal for applications - data centres, servers, storage, Wi-Fi 7 backhaul, AI/ML infrastructure
📌 Short recommendation wifishop.co.uk style
The TP-Link TL-SM9110-SR4 is the ideal transceiver for networks that demand maximum performance and reliability, offering 100 Gbps full duplex over multimode fibre, continuous monitoring and compatibility with advanced equipment. A future-proof investment for data centres and high-end infrastructures.
