Shelly Dali Dimmer 3

🔆 Shelly DALI Dimmer Gen3 – Smart Dimmer for DALI Lighting
Control the brightness of premium DALI luminaires with Shelly DALI Dimmer Gen3 and seamlessly integrate them into your Shelly smart home ecosystem. Perfect for offices, commercial areas, and modern homes, this dimmer offers predictable and customizable light control – no hub required.

✅ Wi-Fi & Bluetooth connectivity – No HUB needed
🔌 Compatible with DALI LED drivers (Part 207)
🔋 Built-in DALI bus power supply – Supports up to 5 DALI lights
🕓 Smart scheduling & automation
🌙 Night mode – Set specific brightness levels during nighttime
📉 Precise brightness control – adjustable min/max limits, fade speed, and transition time
📶 Multi-protocol – Wi-Fi, Bluetooth, KNX, Webhooks support
🔐 Advanced security – Supports MQTT, TLS, HTTPS
🧠 Full compatibility – Alexa, Google Home, and the Shelly Smart Control app

⚙️ Recommended Use Cases
🏢 Commercial lighting – Adjust lighting dynamically in open office spaces, retail stores, and conference rooms for maximum flexibility and efficiency.
🏥 Specialized zones – Perfect for precise lighting in hospitals, labs, operating rooms, and more.
🏠 Retrofit or new builds – Ideal for new installations without classic lighting circuits or to upgrade existing setups.
💡 Smart, cost-effective control – Combine DALI lighting with Shelly smart automation for efficiency, savings, and versatility.

📐 Technical Specifications
Dimensions: 42 x 37 x 17 mm
Weight: 18 g
Mounting: In-wall / suspended ceiling
Housing: Plastic, green color

🔋 Power Supply
Input voltage: 110–240 V~, 50/60Hz
Power consumption: < 2 W

🔌 DALI Bus Output
Nominal voltage: 16 V
Guaranteed current: 10 mA (up to 5 DALI devices)
Short-circuit current: < 35 mA

📡 Connectivity
Wi-Fi: 802.11 b/g/n, 2401–2495 MHz, <20 dBm
Bluetooth 4.2: 2400–2483.5 MHz, <4 dBm
Range: up to 50 m outdoors / 30 m indoors (depending on conditions)

🧠 Processor & Memory
CPU: ESP-Shelly-C38F
Flash memory: 8 MB
Scripting, MQTT, Webhooks: ✔️
Schedules: up to 20

📦 Package Includes:
1 x Shelly DALI Dimmer Gen3
1 x Installation guide
