Home Assistant Green

Home Assistant Green  kit  with pre-installed OS, communication via Apple HomeKit, Amazon Alexa, Google Home and the manufacturer's app, compatible with Android and iOS.

Through it you can integrate almost all smart devices in a single application. The system comes preconfigured by Casa Nabu.

Home Assistant Green contains everything you need for Home Assistant in one box.

Just plug the included power and network cables into the hub and you're up and running.

Home Assistant Green will automatically install the latest version of Home Assistant, the app (mobile or web) will guide you through the setup process and immediately detect your smart devices. This is the easiest way to get started with Home Assistant and is perfect for you or your friends and family who want to take the first step in home automation.

Learn more in the device documentation -> https://green.home-assistant.io/

Hardware specifications

• SoC: Rockchip RK3566 SoC with quad-core Arm Cortex-A55 CPU
• CPU Frequency: 1.8 GHz
• Storage: 32 GB eMMC flash drive
• Memory: 4 GB LPDDR4X

Interfaces

• Status LEDs
  • White (power indicator)
  • Green (activity indicator)
  • Yellow (system health indicator)
• Power supply:
  • DC barrel connector, 5.5 mm * 2.1 mm
  • 12V DC, 1A
• Battery: CR2032. Not included.
• Energy consumption
  • Idle: ~1.7 W at 12 V
  • Load: ~3 W at 12 V
• USB
  • 2x USB 2.0 Type-A Host ports, 5 V up to 2 A (combined)
• Display: HDMI port, for diagnostic purposes only
• External storage: MicroSD slot, for recovery purposes only
• Networking: Gigabit Ethernet port

Dimensions and weight

• Length: 112 mm
• Width: 112 mm
• Height: 32 mm
• Weight: 340g

Materials

• Enclosure: Semi-transparent polycarbonate plastic
• Heatsink: Anodized aluminum
• Packaging: Chipboard

Environmental conditions for operation

• temperatures
  • A °C to 40 °C
  • 32°F to 104°F
• Humidity: Non-condensing
• Room conditions
  • Indoor use only
  • Keep in a dry, not excessively dusty environment as this can cause damage to the unit.

Product information

• Model Number: NC-GREEN-1175
