Shelly Qubino Wave 1 Mini - relay switch 1x 8A (Z-Wave)

Shelly Qubino Wave 1 Mini - Z-Wave® small form factor smart switch with potential-free contacts

The Wave 1 Mini is the smallest Z-Wave smart switch in the world for smart control. It is ideal for automation and remote control of small electrical appliances (up to 8 A), such as electrical locks, gates, garage doors, irrigation system, etc. The output contact is voltage-free (dry contacts), allowing you to connect various power supply loads to the device. Thanks to its compact retrofit design, Wave 1 Mini is a perfect fit for even the smallest switch/electrical boxes or appliances.



ADVANTAGES

• 1 channel up to 8 A at 240 V AC and 5 A at 30 V DC
• Dry contacts
• 35% smaller compared to Shelly Qubino Wave 1
• Extremely low power consumption: less than 0.3 W
• Z-Wave frequency band: 868.4 MHz (CEPT countries)
• Latest technology: Z-Wave 800 Series
• Automatic set-up with SmartStart
• Security 2 Authenticated for the highest level of security
• Supports over-the-air firmware updates
• Fast and simple installation in most electrical boxes and switches
• Works with Z-Wave certified gateways and over 4,000 Z-Wave devices
•

TECHNICAL SPECIFICATIONS

• Power supply 110 - 240 V AC, 50/60 Hz
• Power consumption < 0,3 W
• Max. switching voltage AC 240 V
• Max. switching current AC 8 A
• Max switching power AC 2000 W
• Max. switching voltage DC 30 V
• Max. switching current DC 5 A
• Overheating protection Yes
• Distance Up to 40 m indoors (131 ft.) (depends on local condition)
• Z-Wave repeater Yes
• CPU Z-Wave S800
• Z-Wave frequency bands: 868,4 MHz
• Maximum radio frequency power transmitted in frequency band(s) < 25 mW
• Size (H x W x D) 29x35x16 ±0.5 mm / 1.11x1.35x0.63 ±0.02 in
• Weight 19 ±1 g / 0.65 ±0.04 oz
• Mounting Wall box
• Screw terminals max. torque 0.4 Nm / 3.54 lbin
• Conductor cross section 0.5 to 1.5 mm² / 20 to 16 AWG
• Conductor stripped length 5 to 6 mm / 0.20 to 0.24 in
• Shell material Plastic
• Color Blue
• Ambient temperature -20°C to 40°C / -5°F to 105°F
• Humidity 30% to 70% RH
• Max. altitude 2000 m / 6562 ft
